Function introduction:
> 2.4-inch color display, convenient and intuitive, the touch screen keys have a good user operation experience
>. The main interface status icon, date and time are displayed in real time, and the host status is clear at a glance.
> Support APP remote arming and disarming, parameter setting and accessories management
GPRS real-time networking online to get the latest working status of the device at any time. Automatic alarm offline.
> Multi-task design based on uCOS-III operating system, with excellent user operation experience
> GPRS real-time networking online, to get the latest working status of the device at any time, offline automatic alarm
> Built-in powerful 32-bit Cortex-M3 core-based CPU master
> Reserved remote GPRS TCP / UDP protocol channel, compatible with multiple alarm center networking protocols, convenient for network alarm
> WIFI / GSM / 3G / GPRS network alarm, support multi-channel alarm methods such as APP push, SMS, voice monitoring, central networking, etc., to ensure stable and reliable alarm performance.
> Support SMS remote arming and disarming and parameter setting, support voice channel arming and disarming
> Up to 100 remote controls, RFID cards and wireless detectors to learn storage locations
> Supports multiple defense zone name settings for main door, lobby, distress, bedroom, window, balcony, perimeter, smoke, gas, carbon monoxide, water leakage, etc.
> Support multiple zone types such as in and out zones, internal zones, perimeter zones, 24-hour zones, etc.
> Support multiple extended alarms such as main power failure, backup battery power shortage, anti-pry alarm, etc.
> Up to 5 groups of preset alarm calls, which can be set to SMS switch and dial switch respectively
> External wired siren interface, support external wireless siren
> Can store and query multiple daily operation records and alarm records
> Timed arming and disarming function
> GSM network automatically adjusts time to ensure the clock is always accurate and supports time zone setting, which is convenient for applications in many countries and regions
> Support multi-language (Chinese and English) menu display, voice operation prompt and alarm SMS settings
> Telephone function, support 5 groups of redial numbers
> Can record 10/20 seconds message and alarm voice
Technical Parameters:
Product Name: WIFI + GSM dual network alarm
Number of zones: 99 wireless zones
Wireless frequency: EV1527 / 433 frequency
Wireless distance: 120 meters in the open (optional signal amplifier)
Input voltage: DC5V (micro USB standard interface power supply)
Working current: 120mA
WIFI standard: IEEE802.Ub / g / n wireless standard
Backup battery: 3.7V / 2000mAh lithium battery
Language support: sixteen languages can be switched
Host size: 175 * 134 * 14.7mm (length * width * thickness)
